This article focuses on central chain bucket elevator’s structural features and structural composition, you will more understand central chain bucket elevator through this article.

The structural features of central chain bucket elevator:
The structure of the central chain bucket elevator is as follows: 1. Single-chain single-bucket structure 2. Double-chain double-bucket structure.
This structural performance is particularly suitable for improving the delivery of high temperature, large particles, and abrasive properties.
The central chain bucket elevator is used in clinker conveying system, roller press circulation system and other systems with poor transportation conditions to ensure high efficiency and trouble-free operation of the user, fully satisfying the requirements of modern large-scale cement plants for lifting machines. Reliability, super height, high life and wear resistance requirements.
The structure composition of central chain bucket elevator:
The central chain bucket elevator is composed of a running component, a driving device, an upper device, a middle casing, and a lower device.
1. Running parts: consisting of hopper and central chain, smaller than ZYL1000 adopts single-row chain, larger than ZYL1200 adopts double-row chain.
2. Drive unit: It adopts Y series motor and is composed of coupler and reducer. (can be based on user requirements)
   The drive unit is divided into left and right mounts. Corresponding to the left and right sides of the hoist.
3. Upper device: The main shaft and sprocket are installed.
4. Middle case: There is a standard 3m high, non-standard and maintenance intermediate section in the middle.
5. Lower device: The tensioning device is installed and the weight is tensioned.
